5 Wire Resistive Car Touch Panel / 7 Touch Screen Panel Single
Touch
Shining's 5 Wire Car Touch Panel:
In analog 4-wire resistive technology, one sheet has equipotential
distribution in X direction, and the other sheet has equipotential
distribution in Y direction. The two sheets measure each other’s
voltages. In analog 5-wire resistive technology on the other hand,
one sheet (bottom sheet) has equipotential distribution in both X
and Y directions. Voltage of the bottom sheet is measured by the
top sheet. In other words, the electrodes for both X and Y
directions are placed on the bottom sheet. The top sheet does not
have electrode and just measures the voltage of the bottom sheet.
Specifications:
| Structure | F + G |
| Wiring Method | FPC |
| OD | 164.50*103.00mm |
| VA | 154.50*93.34mm |
| AA | 152.40*91.44mm |
| Transmittance | >78% |
| Touch Life Span | >3,000,000 times |
| Scoring Life Expectance | >1,000,000 times |
| Linearity | <3.0% |
| Supply Voltage | 3.3V DV, 5V DC |
| Chattering Time | <10 MS |
| Operating Temperature | -20℃-70℃, <90%RH |
| Storage Temperature | -30℃-85℃,<90%RH |
| Operating Force | 40-120g |
| Insulation Resistance | >20ΜΩ, 25V(DC) |
